CVO Street Glide Velocity OverDrive Fairing Package AHB-FP-14-ELT-CVO-SG

The AHB-FP-14-ELT-CVO-SG Elite Fairing Package is a high-performing front audio upgrade available for 2014-2023 Harley-Davidson CVO Street Glide models. Engineered for riders who demand the loudest, cleanest, and most dynamic front-stage audio, this Elite system combines component compression horn technology, high-power midbass drivers, and an advanced DSP amplifier designed specifically for Harley touring platforms.

This kit delivers exceptional output even at highway speeds, providing crystal-clear highs and powerful mid-range response without distortion. With true plug-and-play wiring, OEM-fit fairing components, and precision-tuned EQ profiles, installation is clean, fast, and CANBUS-safe. Whether you're running a full AHB system or pairing with Elite bag or Tour Pack upgrades, this front package sets the stage for best-in-class motorcycle audio performance.

KEY FEATURES

• Elite Component Compression Horn tweeters with 6.5” midbass Fairing Speakers

  Maximum projection, wide dispersion, and crystal-clear highs—even at highway speeds.

• DSP-Optimized Tuning

  Pre-engineered EQ maps designed for Harley fairings and saddlebags.

• Ultimate Wiring Package

  Dual 8ga amp power kit, fairing harness, bag harness, and expansion leads.

• Plug-and-Play Installation

  No cutting or splicing of the stock harnesses.

• Upgrade-Ready Platform

  Supports future additions such as Elite Tour Pack or Ultimate Full System expansions.

BENEFITS

• Unmatched loudness and clarity — the most powerful system AHB offers.
• Professional-grade DSP tuning ensures perfect audio detail at any speed.
• Full coverage front and rear for a balanced, high-impact soundstage.
• Future-proof architecture built to expand into AHB’s Ultimate systems.
• High-efficiency design that maximizes performance with minimal distortion.
• Road-tested reliability engineered specifically for Harley touring conditions.

RZ75H:
Impedance 4 Ohms
RE 3.95 Ohms
FS 1571 Hz
QMS 6.129
QES 2.192
QTS 1.614
L @ 10Khz .01128 Mh
Sens 107 db

R65:
Power Handling - Continuous - 150Wrms
Power Handling - Peak - 400Wpeak
Impedance - 4Ω
Frequency Response - 100Hz to 10kHz
Magnet Neodymium
Cone Water repellent pressed paper

RZA500.2:
Peak Power: 650 Watts
RMS Power:
2 x 275W @ 2 Ohms
2 x 150W @ 4 Ohms
1 x 550W @ 4 Ohms (bridged mode)
Frequency Response: 20 Hz–25 kHz
Crossover Range: 40 Hz–400 Hz (12 dB slope)
Signal Input Range: 0.41V–10V (balanced high/low level)
Efficiency: 87% at full power
Dimensions:
Housing size: 7.125 x 4.125 x 1.5625"
With Mounting bracket: 8.0 x 4.125 x 1.5625"
